Creating a Logging Appender

You can create a logging appender from the GUI or by using the CLI. Three types of appenders are supported: Clear Text File.

GUI

Procedure
1. Select Shared Objects > Logging Appenders.

2. Click New.

   The New Logging Appender dialog displays with the dropdown list of the logging appender type expanded.

3. Select an appender type from the Type list.

   • Clear Text File - Appends events to a file in the clear text format.

   The dialog redraws with the appender-specific fields.

4. Accept the default name or type a name for the appender in the Name field.

5. Fill in the fields and click Save.

The appender is added to the Logging Appenders table and is selected.

Result

CLI

Procedure

1. In the logappender_data.xml, specify the type of the appender in the xsi:type attribute.

   File Log Appender

   <LogAppender
    xsi:type="amxdata:FileLogAppender"
    name="HelloWorldFileAppender"
    description="This is File LogAppender"
    filePath="C:/amx-3admin/tibco/cfgmgmt/tibcohost/Admin-amxadmin-instanceOne/
    nodes/DevNode/logs/HelloWorld.log"
    maxSize="10000" maxBackupNum="5"/>

2. In the logappender_build.xml, for the AMXAdminTask element, set the action attribute to add and the objectSelector attribute to LogAppender.

   <AMXAdminTask action="add" objectSelector="LogAppender"/>

3. Invoke the command-line interface on the build file (logappender_build.xml) using the following command:

   ant -f logappender_build.xml create

   For information on how to retrieve log entries from the destination queue of a JMS appender, see TIBCO ActiveMatrix® Service Grid Composite Development.
