Get Key Mapping Response

The response specification is as follows:

Queue or Topic	Queue
Destination	The temp queue or JMSReplyTo destination or `tibco.aff.tds.keymapping.reply` queue

The response message contains the following header properties:

Element	Type	Cardinality	Description
businessTransactionID	String	Optional	The unique identifier for tracing across function calls. This is used for logging.
correlationID	String	Optional	The unique identifier for tracing purposes across a single function call. This is generally used by the calling application to correlate requests and responses.
success	Boolean	Required	The flag indicating if the call was successful.
messageCode	String	Required	The result message code.
message	String	Required	The result message.
orderID	String	Required	The internal unique identifier for the order.
orderRef	String	Required	The external unique identifier for the order.
planID	String	Required	The internal unique identifier for the plan for the order if it exists.

The response message contains the XML payload according to the following schema:

Get Order Response

The following table lists the details of the elements.

Element	Type	Cardinality	Description
businessTransactionID	String	Optional	The unique identifier for tracing across function calls. This is used for logging.
resultStatus	Type	Required	The result status type. See Appendix A for the specification of this type.
orderID	String	Required	The internal unique identifier for the order.
orderRef	String	Required	The external unique identifier for the order.
planID	String	Required	The internal unique identifier for the plan for the order if it exists.
